Solar Adsorption Refrigeration Cycle (AC35-CH3OH) | Matlab | Simulink Model

Solar Adsorption Refrigeration Cycle (SARC) system is similar to vapor compression system in which compressor is replaced by solar heat driven adsorption bed. The adsorption bed is integrated with a flat plate solar collector (FPC/Bed REactor) and contains a porous adsorbent medium (low grade charcoal). The adsorbed content of refrigerant varies cyclically, depending on the adsorbent temperature and system pressure, which varies between a maximum limit set by the condensation pressure and a minimum limit imposed by the evaporation pressure. Refrigerant used is Methanol (CH3OH) as it has greater affinity towards the salt (Activated carbon). This model is a design model for Solar Adsorption Refrigeration Cycle (SARC). Solar flat plate collector is attached to the bed reactor for heat generation process. The cycle contains the following: 1-Evaporator. 2-Bed reactor tank. 3-Solar collector (FPC/water). 4-Condenser. 5-Expansion valve. 6-Activated carbon is used as a bed salt. 7-Methanol CH3OH is used as a main refrigerant.    • Solar Adsorption Refrigeration Cycle (AC35...   **MatLab-SimuLink should be used to run the model. Copyright © 2007 by Mohamed A. Sharaf Eldean Ayoub Model download link: https://www.redslibrary.com/product-p... REDS Library online shop: https://www.redslibrary.com/shop Follow us on Twitter:   / sharafdr   Follow us on Facebook:   / redslibrary
