Glue Track, Connector Pin, and BGA Array Scanning with Gocator and Chen Shen!

Explore the advanced 3D scanning capabilities of LMI Technologies' Gocator sensors. In this demo, we walk through several real-world inspection examples to showcase the precision and flexibility of our technology. First, we scan a BGA array using the Gocator 4010. With a 1.9-micron X resolution and excellent angular response thanks to its coaxial confocal design, the sensor captures detailed top-surface data with no loss of information. Next, we demonstrate how the 4010 handles curved glass—showing how well it captures sloped, reflective surfaces without shadowing. The data is stitched into a complete surface model, ideal for full-object inspection. We also dive into glue track inspection using our custom-developed track tool. The system easily detects multiple measurement points along a single glue path, including wall height, peak profile, width, and area. Once a track is defined, the tool can automatically register and reuse that setup on future scans—making recipe creation fast and repeatable. Then we show a pin connector scan using GoPxL’s batch processing features. Instead of manually setting up each inspection point, the software allows you to define one tool relative to a reference point and automatically apply it across the entire array—saving significant setup time and increasing consistency. This demo was recorded at our Cupertino TKH Vision Center, where we showcase a variety of Gocator sensors and GoPxL tools. If you're interested in learning more or want to schedule a live demo, reach out—we’re happy to help. For more information, visit https://lmi3d.com #3DVision #ConfocalSensor #Gocator4010 #MachineVision #GoPxL #LMItechnologies The global leader in 3D scanning and inspection, LMI Technologies works to advance quality and productivity with 3D sensor technology. Our award-winning, FactorySmart® laser, snapshot, and line confocal sensors improve the quality and efficiency of factory production by providing fast, accurate, reliable inspection solutions that leverage smart 3D technologies. Unlike contact based measurement or 2D vision, our non-contact solutions add 3D shape information that is critical to achieving 100% quality control. Twitter:   / lmi3d   LinkedIn:   / lmi-technologies   LMI Blogs: https://lmi3d.com/digital-hub/?catego... Introduction to LMI:    • What Makes Gocator Smart? – An Introductio...   #MachineVision #Gocator #FANUC #IndustrialAutomation #EtherNetIP #LMItechnologies
