S31: Shoe Grinding Bearing Ring

Highest precision for thin-walled workpieces - shoe grinding of a bearing ring on the universal cylindrical grinding machine S31. Shoe grinding is a cylindrical grinding process in which highprecision, thin-walled workpieces, with high requirements on roundness and concentricity between internal and external diameter, are machined in a so-called shoe grinding fixtures. The supporting shoes of the shoe grinding fixture hold the workpiece in the center. Torque transformation and holding force are ensured by the electromagnetic chuck. The holding force can be programmed in different stages. Our shoe grinding fixtures are available in six different sizes and cover a diameter range of 10 - 460 mm (0.4"-18.1"). https://www.studer.com/en/produkte/au...
