BMW ENET data cable OBD2 to ethernet

Making and testing DIY data cable for BMW #ENET communication system. This cable is very easy to make it yourself if you have soldering iron and basic knowledge about electronics. Thanks to this cable you can connect with #BMW Fxx cars (F07, F01, F30...) and some late Exx cars (like X1 E84 with CIC navigation in the video). This cable can also be used with software like: BMW E-SYS, INPA, ISTA and others to perform coding, diagnostics and programming procedures. You will need: 1. RJ45 ethernet cable 2. OBD2 connector: http://s.click.aliexpress.com/e/FqbL1uy 3. 510-560 Ohms resistor OBD2 connector pinout: 3 - green-white ethernet line 4 - bridge to pin 5 5 - bridge to pin 4 8 - bridge with pin 16 using the resistor 11 - green ethernet line 12 - orange-white ethernet line 13 - orange ethernet line 16 - bridge with pin 8 using the resistor http://mr-fix.info/ Facebook:   / mrfixpl   Instagram:   / mrfixpl   Pinterest:   / mrfixpl   Instructables: http://www.instructables.com/member/m...
