Paia 2720 3L Lowpass filter - DIY Modular in a Week 7.1

I begin day 7 with a pretty mellow filter. The Paia 2720-3L is a lowpass filter with no resonance. It is still a nice filter to shape the harshest overtones of a sound. quite an easy build but could be a little more complicated (and better) by adding a CV summing mixer for the CV input and freq knob. That is discussed in this video but not shown. For info on how to build a cv summing mixer take a look at MiaW 1.2:    • Classic 2 Op-Amp  tri and square wave VCO ...   Day 7: Filters Part 1: Paia 2720-3L Lowpass filter Difficulty: Intermediate/Easy... Price: ~4$ MiaW playlist:    • Modular In A Week (MIAW)   Visit my Patreon page for more (different) content, or if you just want to support my work more than just a thumbs up :)   / sourceryone   Link to the schematics on SynthDIY.com: http://www.synthdiy.com/files/2004/PA... Front panel design: https://www.dropbox.com/s/sr17fhhdm0p... Link to the component spreadsheet: https://www.dropbox.com/s/fn9gbn0vo0f... Link to my dropbox folder where ALL the files for all the episodes as they become available: https://www.dropbox.com/sh/ynbxdv9nn6...
