Example 3.4.a How to model a laminated composite using with thin shell elements in Abaqus

Example 3.4 is spread out over four videos because it shows you four ways to solve the same problem. In this Part (a), we use thin shell elements. We show you how to model a laminated structure by providing properties and orientations of each lamina in the laminate. We illustrate techniques to name those laminas, and later use that to extract results for each lamina. We show you how to visualize using multiple plot options, contours, and displaying material orientations. Additional details in the textbook "Finite Element Analysis of Composite Materials Using Abaqus." Multilingual CC available. Textbook: https://www.amazon.com/exec/obidos/AS... You can teach "Composite Materials Design" and assign online homework to your students. 112 problems available. If you want an instructor account, leave a message in the comments section for    • Webwork online-homework demo, advantages a...   Table of Contents: 00:00 - Introduction 00:53 - Set Work Directory and Save 01:23 - Part 01:44 - Lamina properties 02:51 - Section properties 04:07 - Assign section to part 04:23 - Assembly parts into an assembly 04:35 - Step 04:45 - Field Output Request 06:02 - Shell edge load 06:35 - Mesh 07:24 - Mesh 07:37 - Create node sets 07:55 - Set y-hold 08:16 - Set edges 08:46 - To Module Load again 10:03 - Job 10:23 - Results 10:30 - Viewport annotation options 11:22 - Allow multiple plot states 11:37 - Material orientations 11:53 - Section points 12:47 - Contour plots 13:25 - End card
