3D truss modeling in Abaqus

Now, it's time to learn the Abaqus with a practical example. 3D truss modeling. A truss is made up of a collection of two-force members to form a rigid structure. A structural component with only two points of force is referred to as a "two-force member." Trusses are most frequently used in structures, where it is easy to give support for the roofs, floors, and interior loads like services and suspended ceilings. In this video, you learn how to model a truss in the Abaqus step by step from the Part module to the Job module. In the end, the results will be analyzed. Learn Abaqus like a pro with us: https://caeassistant.com/free-abaqus-... Abaqus for beginners package: https://caeassistant.com/product/abaq... https://caeassistant.com/product/abaq... 0:00- Problem description 0:45- Modeling the truss 6:50- Define material properties 8:20- Assembly 8:50- Defining the type of the analysis 9:20- Boundary conditions 11:45- Meshing the truss 12:55- Run the analysis 13:20- Results Music: Bensound.com/free-music-for-videos
