plc project 3

project plan: The system includes two three-phase asynchronous motors, M1 and M2. When the Start button is pressed, the M1 motor starts, runs for 7 seconds, and then stops. Once M1 stops, a 3-second delay period begins. After this delay, the M2 motor starts, runs for 10 seconds, and then stops. After M2 stops, the system waits for 5 seconds. At the end of this period, M1 starts again and runs for 7 seconds before stopping. This operational cycle continues continuously and periodically until the Stop button is pressed. The L1 signal lamp will be active while the system is running (whenever any motor is active). The L2 signal lamp will be active while the system is in a delay/waiting period. When the Stop button is pressed, all motors stop, and the system returns to its initial state. thank you ...
