FreeCAD Draft Dimensions and Dimension Styles Overview

In this video I provide a comprehensive overview of Dimensions and Dimension styles of the FreeCAD Draft workbench. As part of the tutorial, I provide information about the setup of default dimensions style, including arrow style, text offset, text height, dimension and extension lines overshoots (extensions), units setup and override. Creation of dimension is shown, including continuous dimensions and how to edit existing dimensions. Creation of angular and diameter dimensions is demonstrated in the video too. Styles of dimensions is also described, including the difference between default dimension styles (which are saved as part of the FreeCAD installation) and annotation styles (which are saved as part of the FXStd file). The difference between World and Screen Display mode settings is also explained. FreeCAD version used in the video: 0.21.2 Follow on LinkedIn:   / fcblounge   Follow on BlueSky: https://bsky.app/profile/tomaspolak.b... Chapters: 00:00 Introduction 00:20 Creating linear dimensions 01:50 Default dimension style setup 08:19 Units setup 09:02 Dimension text orientation 10:00 Edge dimension 10:40 Radial dimension (diemeter) 11:00 Angular dimension 11:25 Editing dimensions 13:14 Dimension font setting 14:06 Setting world and screen display mode 15:45 Setting scale multiplier (scale of dimensions) 16:54 Turning annotation scale widget on 19:13 Continuous dimensions 20:20 Unit override 22:30 Saving default dimension styles 24:37 Using annotation styles Check out FreeCAD here: https://www.freecad.org/ This video was created with the help of OBS: https://obsproject.com/ This video was created with the help of GIMP: https://www.gimp.org/ This video was created with the help of KDEnlive: https://kdenlive.org/ #FreeCAD
