AL-336D DELUXE Centre Lathe HAFCO Metalmaster - 60 Seconds (L682D)

http://www.machineryhouse.com.au/l682d AL-336D DELUXE - Centre Lathe (240V) Description A high quality specification, floor standing, heavy duty metal turning lathe suitable for the keen model engineer, general maintenance and small production work shops. Featuring a precision ground, induction hardened bed, fully gear driven spindle with hardened and ground gears with a speed range of 65 - 1810rpm, selectable via the front of headstock mounted gear selection levers. 2HP single phase 240V motor is supplied on machine, taper roller spindle bearings, range of cross and longitudinal feed speeds selected on a separate gearbox, thread chasing dial, spindle foot brake, chuck guard with safety interlock, guarded leadscrew, splash guard, coolant pump system, work lamp, digital readout on a separate panel. Supplied with a large range of standard accessories including a 150mm(6") 3 jaw self centring chuck, 200mm(8") 4 jaw independent chuck, face plate and dead centres. 5 to 3 MT reduction sleeve, steady rest, follow rest, quick change tool post with 4 tool holders. The floor stand is supplied with a swarf tray and incorporates a foot brake. Change gears and toolbox with maintenance tools. The overall capacities are 900mm between centres and 300mm swing over the bed. A gap bed facility gives 450mm swing. Thread cutting facilities in Metric & Imperial with a reversible leadscrew, the thread chasing dial provides easy re-engagement of the leadscrew in the correct position. (note the thread chasing dial is designed for imperial only). Features 2 Axis digital readout Quick change toolpost with 4 holders Gear drive headstock for quick change of spindle speeds Precision 'V'-beds are hardened and ground, incorporating a rigid webbed casting Concertina leadscrew cover Slide out swarf tray from front of machine Low voltage work light Foot operated spindle brake with safety cut out switch Slide out front swarf tray for easy cleaning Change gears for metric and imperial thread cutting Oil sight glass for head stock and gearbox Adjustable taper roller bearings support the spindle 18 spindle speeds from 65 to 1810rpm Inching button is incorporated on the control panel for convenient spindle speed selection Enclosed quick action gearbox for thread cutting and auto feeding Powered longitudinal and cross feeds D1-4 camlock spindle for quick chuck changes and safe reverse direction turning. ISO standard Removable gap bed-way for larger diameter jobs Dual calibrated dials (except for saddle hand-wheel) Chuck & change gear guards are fitted with micro switches Includes 2 Axis digital readout system Concertina leadscrew cover Quick change toolpost with 4 holders Slide out front swarf tray 3-jaw chuck with reverse jaws 4-jaw chuck Face plate Fixed steady Travelling steady Coolant system Change gears Dead centres Thread-chasing dial Safety chuck guard Work light Stand Foot brake Rear splash guard & slide out swarf tray Tool box Instruction booklet ORDER CODE: L682D Model: AL-336D-DELUXE Digital Readout System Fitted: Yes Quick Change Toolpost Fitted: Yes Leadscrew Covers Fitted: Yes Coolant System: Yes Tool Height To Suit: 12mm Distance Between Centres: 900mm Swing Over Bed: 300mm Swing Over Cross-slide: 180mm Swing In Gap: 450mm Centre Height: 150mm Spindle Bore: 38mm Spindle Nose Size or Type: D1-4 Camlock Bed Width: 180mm Headstock Spindle Taper: 5MT Tailstock Taper: 3MT Cross Slide Travel: 170mm Compound Slide Travel: 75mm Leadscrew: Imperial Cross Feed Range (X-Axis): 0.009 - 0.236mm/rev Longitudinal Feed Range (Z-Axis): 0.04 - 1.2236mm/rev Metric Thread Steps & Pitch Range: 32 (0.4 - 7mm) Imperial Thread Steps & TPI Range: 36 (4 - 60tpi) 3 Jaw Chuck Diameter: 160mm 4 Jaw Chuck Diameter: 200mm Spindle Steps / Speed Range: 18 (65 - 1810rpm) Motor Power: 1.5kW / 2hp Voltage: 240V Weight (nett): 595kg For more information on this machine, please visit: Hare and Forbes Machineryhouse Sydney: (02) 9890 9111 Melbourne: (03) 9212 4422 Brisbane: (07) 3715 2200 Perth: (08) 9373 9999 http://www.machineryhouse.com.au/L682D Machineryhouse - NZ Auckland: (09) 2717 234 http://www.machineryhouse.co.nz/L682D
