Teardown and analysis of Telensa Telecell lighting control system that apparently can ZAP you..

Various people (OK, only one, we all know who) claims that these Telensa devices have: Unusual 450v capacitors and super-capacitors to zap you. A directional antenna. A 3300watt relay to control some zapping thing. The ability to, err, track/vaporise/something you.. So I found one on eBay and take it to bits with an actual look at the components and links to the data sheets below. Here are the links to the data sheets on the components: Install details for the Telensa units: https://fccid.io/XYD-2NXN/User-Manual... LED driver: https://www.mouser.co.uk/datasheet/2/... (Page 5 has an example circuit diagram with 450v capacitors, especially for Mark to learn from.) RF transceiver: https://datasheetspdf.com/pdf-file/95... Relay: https://www.hongfa.com/product/detail... RF receive flter: http://www.farnell.com/datasheets/175... GPS chip: https://www.skytraq.com.tw/products/V... power monitor chip: https://www.nxp.com/docs/en/fact-shee... STM32 MCU: https://www.st.com/resource/en/datash...
