Temperature Control With Arduino Uno | up to 1000 degrees Celsius | K Type Thermocouple

Temperature Control With Arduino Uno | up to 1000 degrees Celsius | K Type Thermocouple This video is related to the construction of a temperature controller with Arduino. This controller creates commands in the output by measuring the temperature and checking it. The parts used in this project: 1- Arduino UNO R3 2-7 segment 4-digit module with TM1637 driver 3- single channel 5 volt relay module 4- 12 volt cooling fan 5- Thermocouple module MAX6675 type K The way this controller works is that by heating the temperature sensor, the temperature starts to increase. When the temperature reaches a certain number (here 50 degrees Celsius), the Arduino commands and the fan turns on until Reduce the temperature of the sensor. Also, when the temperature of the sensor reaches below 50 degrees Celsius, the fan turns off. Wiring: Thermocouple: SO=Pin 4 Of Arduino CS=Pin 5 Of Arduino SCK=Pin 6 Of Arduino Seven segment: CLK=Pin 2 Of Arduino DIO=Pin 3 Of Arduino Relay module: Input Pin=Pin 10 Of Arduino Write your opinion about this video in the comments. If you like this video, please like it and subscribe to my channel and press the bell to get notified of my latest videos.
