How to assemble the rotary encoder with machanism BSL GA55B？

Prepare the components: Rotary encoder that meets the required size, draw-wire mechanism BSL-GA55B, screwdriver, hex wrench, screw, utility knife step1: Loosen the 2 hexagonal socket screws on the spring pot; insert a utility knife into the gap of the pot, press the wheel to prevent the wheel from popping out. Remove the flange. step2: Assemble the encoder and flange together, and fix them with 3*M3 screws. Step3: Place the milling surface of the D-shaft of the encoder on the exact position of the center hole of the hub, and combine the encoder with the string pot and fix it with 2 M4 bolts. Such a perfect draw-wire encoder is assembled.
