XFly Twinn 40mm F22 Assembly, Setup, CG and Tips!!

Features: 4 operable channels (Aileron, Elevator, Throttle, Steering) Streamlined and true-to-scale design Efficient twin power system setup delivering an abundance of thrust for fast climbs, rolls, loops Low wing load and full flying stabs design for excellent high alpha capability Perfectly fitted landing gear design for smooth takeoff and landing Extended flight time of 3-8 mins when using recommended 4S 1300-2600mAh LiPo battery All components can be assembled quickly without glue needed Molded-in finger grips for easy hand launch Robust EPO construction Wingspan 702mm (27.6 in) Length 955mm (37.6 in) Wing Load 89g/dm2 Wing Area 10.6dm2 Flying Weight Approx 950g (2.1 lb) CG (Center of Gravity) 80mm from the leading edge Drive System Two 1413-KV5000 inrunner brushless motors EDF Diameter Two 40mm (12-blade impeller) Galaxy X-4 Landing Gears Fixed main landing gears, steerable nose gear Servo Five 9g ESC Two 20A Approx Flight Time Up to 8 mins Assembly Time Approx 10 mins Recommended Battery (Not Included) 14.8V 1300mAh~2600mAh Lipo www.bananahobby.com/4-ch-xfly-model-f-22-raptor-twin-40mm-rc-edf-jet-pnp.html
