Tungaloy x NTK — Precision Machining of a Turbine Blade for Aerospace

Precision turbine blade machining with advanced Tungaloy and NTK solutions, delivering stable performance, high accuracy, and productive machining in demanding aerospace alloys. ■Tungaloy Corporation    / @tungaloycorporation   ■NTK https://ntkcuttingtools.com/article/r... ■Tungaloy https://tungaloy.com/industries/aeros... ■Work Material: INCONEL 718 ■Machine: BBT40 5-axis machine (22/15 kW) Cutting Tools & Conditions ■Products: JRF Milling Cutter Tool: JRFMH025E250R04 (Z=4) Insert: RNGF060400E-HNF SX3 https://ntkcuttingtools.com/products/... Roughing / Dry Vc = 700 m/min (2,296 sfm) fz = 0.08 mm/t (0.0031 ipt) F = 2,852 mm/min (112 ipm) ap = 1 mm (0.0393") ■Products: CERAMATIC Brazed Tool: RCEM120J6R150B (Z=6) SX9 https://ntkcuttingtools.com/products/... Roughing / Dry Vc = 350 m/min (984 sfm) fz = 0.04 mm/t (0.0016 ipt) F = 2,228 mm/min (88 ipm) ap = 1 mm (0.0393") ■Products: AddForceBarrel Tool: HFZN10M020M10R04 (Z=4) Insert: ZNHU1003R30-MM AH9130 https://tungaloy.com/product/milling/... Semi Finishing / Wet Vc = 60 m/min (196 sfm) fz = 0.1 mm/t (0.0039 ipt) F = 450 mm/min (18 ipm) ap = 2 mm (0.0787") ■Products: TungMeister Tool: VTSD12L080S05-S Head: VBD080L05.0-BG-02S05 (Z=2) AH725 https://tungaloy.com/product/milling/... Finishing / Wet Vc = 40 m/min (131 sfm) fz = 0.04 mm/t (0.0016 ipt) F = 127 mm/min (5 ipm) ap = 0.8 mm (0.0314") ■Products: TungMeister Tool: VTSD12L080S05-S Head: VBD060L05.5-BG-04S05 (Z=4) AH725 https://tungaloy.com/product/milling/... Finishing / Wet Vc = 50 m/min (164 sfm) fz = 0.04 mm/t (0.0016 ipt) F = 425 mm/min (17 ipm) ap = 0.5 mm (0.0196") Contact us: https://ntkcuttingtools.com/contact/ https://tungaloy.com/contact/#contact... #cnc #machine #engineering #aerospace #turbineblade
