Hitachi LE55A6R9 LE55A6R9A LED Strip Replacement Tutorial - No Backlight Replacement for LED Strips

Hitachi LED Strip Replacement Tutorial CLICK HERE for Replacements: http://www.shopjimmy.com/hitachi-lb55... Hitachi LE55A6R9 LE55A6R9A This video is designed to be a guide. Please note that other complications may exist that are not addressed in this guide. Try all repairs and troubleshooting at your own risk. In this video we will show how to replace the Hitachi LED strips for the following TV models we have put on the screen. These strips may also be used in other Hitachi TV models. Be sure when purchasing replacement LED strips to check the listing on our product page for those LED strips to be sure you have matched the correct information to be sure you are purchasing the correct replacements. When replacing LED strips, you will have to remove the panel. Removing the panel can be very difficult. If your TV panel is damaged during the replacement process, you will have to get a replacement TV. Start by removing the screws and back cover off the TV. Flip up the tabs and carefully disconnect the ribbon cables from the buffer boards. Remove the remaining screws that hold the bezel to the chassis. We are using a tester TV for this video. This TV has been used for testing boards and other TV parts, so our TV may look a little bit different, or we might not have as many screws in certain areas, like your TV may have. This video is intended to serve as a general tutorial. Unscrew and remove the speakers. You can put the speakers onto the chassis, so that they stay put, if you flip up the speakers , the metal back will hold onto the metal chassis and stay in place. Very gently loosen the buffer boards on the bottom of the TV and release them from the tabs that hold them in place. After releasing them from the tabs and getting them loose, there may be a piece of tape that needs to be removed. Next, remove the bezel. use a putty knife or five in one tool and slide it along the bezel to detach it from the chassis. After detaching the bezel, lift it and remove it from the TV. Flip up the buffer boards and using blue painters tape, attach them to the TV panel. We are using suction cups in this video, which are highly recommended for removing the panel. You could also use a few sheets of plastic or something similar underneath the panel to lift it away. Be sure you do not allow the panel to bend or flex. if the panel cracks or breaks, you will need to replace your TV. Remove the screen holding frame, also known As the frame. After removing the frame, take the layers of diffusion and tape them together in the corners. This will help to keep them together and in order before removing them. It will also help when you are re-assembling the TV. Lift and remove the layers of diffusion. The screws are removed in our TV, but your TV might have screws that hold the reflector to the chassis. Remove the screws that hold the reflector sheet to the chassis. Also remove any clips that may be holding it down. Gently remove the reflector sheet. Disconnect the wires at each of the LED strips. There may be screws that secure the LEDs to the chassis, if so, remove those screws. Use a five in one tool to remove the LED strips From the chassis. Take your replacement strips and install them. We are using double sided tape as we no longer have the screws from our original strips. On your strips, reinstall them with the original screws. After aligning the replacement strips, reconnect them to the wires. Reinstall the reflector. Insert the screws and clips to secure the reflector to the chassis. Align and install the layers of diffusion. Remove the tape in the corners. Reinstall the frame. Align the panel. Be sure to check the corners to be sure they are properly aligned, so they don't get pinched or cracked. Damaging the panel will result in the need to purchase a new TV. Remove the tape and release the buffer boards. Reinstall the bezel. There may be screws on the bezel that need to be installed. Lock the buffer boards back into the tabs to keep them secure. Reinstall the speakers and connect the ribbon cables to the buffer boards. Carefully reconnect the ribbon cables to the buffer boards. Reinstall the back cover and turn the TV on to be sure the TV is working correctly. TV Repair Made Easy™ © 2017 ShopJimmy.com, LLC.
