Dell 3100 Non-Touch | Chromebook Teardown Guide

Learn how to easily teardown your Dell 3100 Chromebook in our quick step-by-step guide! If you're still struggling, feel free to visit our website www.ChromebookParts.com and we can assist you with any of your device management needs. Teardown Guide: Step 1: Detach 9 screws from the bottom cover. Remove the bottom cover. Step 2: Unplug the battery from the motherboard. Step 3: Unscrew the Wi-Fi fastener, and pullback the wires. Step 4: Unscrew the LCD fastener, flip the tab up, and pullback the cable. Step 5: Remove the 6 Hinge screws and separate the LCD Assembly from the Palmrest. Step 6: Remove the 4 Stickers and Screws from the Bezel. Carefully remove the Bezel. Be mindful of adhesive. Step 7: Remove the 4 LCD Bracket screws and lift up the LCD from the top. Step 8: Unseat the LCD Cable from the LCD. Step 9: Unscrew the 6 Hinge screws. Lift up the hinges. Step 10: Using a thin tool, carefully slide under the camera board and lift up the camera. Step 11: Unplug and detach the LCD/Camera Cable. Step 12: Remove the 3 Battery screws and lift the battery up. Be mindful of adhesive on the top left corner. Step 13: Firmly (but gently) unplug the speaker cable from the motherboard. Pull out speakers. Step 14: Remove the 3 bracket screws. Unplug the touchpad cable. Step 15: Remove the 3 Touchpad screws and lift the Touchpad out of place. Step 16: Remove 2 screws from the daughterboard, and detach 3 cables connected to the motherboard. Pull out the daughterboard. Step 17: Unscrew 4 screws from the motherboard, detach the palmrest cable, then lift the motherboard out.
