ExactTrak Radar Sensor: High Accuracy Electromagnetic Radar Sensor for Metals Furnaces

The Fife ExactTrak Radar Sensor delivers high-speed, noncontact center position control for metal strips in high temperature treatment lines. It is a superior performance and reliability alternative to traditional capacitive or inductive sensors used today in continuous process furnaces. The ExactTrak system features two radar sensors, each mounted outside of the furnace on opposite sides. The sensors emit electromagnetic radar waves through an insulated window onto the edges of the metal strip as it travels through the furnace. The radar waves reflect off the metal strip back to the sensors’ dual receivers, which determine the strip position based on the time it takes for the radar waves to return. Finally, the Fife D-MAXE digital signal processor uses these signals to calculate the center position of the strip, and drives the actuated guide to adjust the lateral strip position in real-time.
