Subsea Energy Solutions | SUB-FLEX-VIV Animation | FPSO Animation

SUB-FLEX-VIV™ is an advanced solution developed by Subsea Energy Solutions, designed to mitigate vortex-induced vibration (VIV) in subsea pipelines, risers, and other structures exposed to hydrodynamic forces in underwater environments. What is Vortex-Induced Vibration (VIV)? VIV occurs when fluid flows past a cylindrical structure, creating alternating vortices on either side of the structure. These vortices generate oscillating forces, which can cause the structure to vibrate. Over time, VIV can lead to fatigue damage, impacting the integrity and lifespan of subsea equipment. Technical Specifications of SUB-FLEX-VIV™ 1. Design and Material Material Composition: High-performance polymers or composites with exceptional fatigue and corrosion resistance. UV-resistant and hydrodynamically optimized materials. Flexibility: Adapts to various pipeline diameters (customizable range from 4 inches to 48 inches or more). Durability: Tested for high-performance operations at depths up to 3,000 meters. Resistant to saltwater, hydrocarbon exposure, and marine growth. 2. Hydrodynamic Performance VIV Suppression Efficiency: Reduces vibrations by up to 85% depending on flow conditions and installation. Drag Coefficients: Tailored design to minimize drag while mitigating oscillations. Flow Velocity Range: Designed to operate effectively within a flow velocity range of 0.2 to 3.5 m/s. 3. Installation Specifications Easy Deployment: Modular design enables quick installation using standard offshore tools. Compatible with both diver-assisted and ROV (Remotely Operated Vehicle) operations. Attachment Mechanism: Innovative clamp-on or strap-on solutions that ensure secure fitting without damaging the structure. Installation Time: Reduced by approximately 40% compared to conventional VIV suppression devices. 4. Operational Range Temperature Tolerance: Operates efficiently in temperatures ranging from -40°C to +100°C. Pressure Resistance: Designed for high-pressure environments, exceeding 300 bar. Service Life: Expected operational lifespan of 20+ years with minimal maintenance. 5. Compliance and Certification Industry Standards: Compliant with API RP 2RD, DNVGL-RP-F105, and ISO 13628 standards for subsea structures and risers. Environmental Impact: Environmentally friendly materials with minimal ecological footprint. 6. Additional Features Custom Design Options: Tailored to meet specific project requirements, including unique hydrodynamic or structural challenges. Integrated Monitoring: Optional sensors can be integrated to monitor vibration and performance in real-time. Maintenance: Designed for zero to minimal intervention during its operational life. Applications Suited for offshore oil and gas fields, including deepwater and ultra-deepwater operations. Ideal for use in renewable energy projects, such as wind farm cable protection. About International Energy Club International Energy Club is a world-renowned offshore animation studio known for its commitment to excellence and innovation in visual storytelling. With a diverse portfolio spanning various genres and mediums, the studio continues to captivate audiences worldwide with its captivating animations. To know more about us & our capabilities in the field of offshore, marine & subsea animations, you can visit our website. http://www.internationalenergyclub.com/ 🔔 Don’t forget to like, comment, and subscribe to our channel for more animations showcasing the latest innovations in offshore, marine, and subsea industries! #OffshoreAnimation #3danimation #offshore #marinetechnology #marinetech #animationvideo #subsea #energy #offshoreanimations #fpso #maritime #transport #ship #vessel #InternationalEnergyClub #MaritimeShipping #marinehoses #fuelingthefuture #fuelinjection #bunkering #bunkeringAnimation #subseatechnology #VIV #FPSOanimation #oilandgas #underwater
