FlightStream® Meshing Tutorial

FlightStream® meshing tutorial #FlightStream #FlowSolver #MeshingTutorial This video demonstrates FlightStream® meshing best practices for Trimmed and Aligned mesher tools. The Piper PA-24 is used as an example for these two mesher tools. Learn more from https://www.darcorp.com/flightstream-... Table of Contents: 00:00 - Introduction 00:03 - Trimmed vs Aligned mesher 00:32 - Check Tessallated Vertice and Face Count 00:59 - Use PA-24 wing as example aircraft 01:05 - Resize CAD scene window 01:10 - Trimmed mesher setup on wing 01:56 - Trimmed mesher setup on rounded wingtip 02:34 - Criteria for Aligned mesher tool 03:22 - Aligned mesher setup on wing 03:56 - Arrange Aligned mesh vertices if necessary 04:29 - Identify Aligned mesh Source, Target, Sweep 1 and Sweep 2 04:45 - Aligned mesh Subdivisions setup 04:53 - Aligned mesh Growth scheme and Growth rate 05:09 - Compare faces and vertices count between Trimmed and Aligned mesh 05:21 - Chordwise direction subdivision setup tip 05:52 - Repeat Aligned mesh setup on wing bottom surface 06:13 - Increase Sweep subdivisions for longer span surface 06:30 - Apply Aligned mesh to rounded wingtip 07:00 - Apply Aligned mesh on horizontal tail 07:05 - Apply Aligned mesh to surface with more than 4 corner vertices 07:33 - Final comparison of faces and vertices count
