PLC Se Star Delta Controlling & Power Wiring Kaise Kare | Star Delta Starter PLC Hindi 📝 YouTube Description (SEO Hindi) Is video me hum aapko PLC se Star Delta Motor Controlling aur Power Wiring step-by-step samjhayenge. Aap jaanenge Star Contactor, Delta Contactor, Timer Logic, PLC Input Output Mapping aur 3 Phase Induction Motor ko PLC ke through kaise control kiya jata hai. [2:29 pm, 11/1/2026] Gk Electricals Trading Co: PLC Star-Delta Ladder Logic – Basic Concept Star-Delta control me motor pehle STAR me start hoti hai, phir delay ke baad DELTA me shift hoti hai taaki starting current kam rahe. 🔹 Required Inputs (PLC INPUT) I0.0 – START Push Button (NO) I0.1 – STOP Push Button (NC) I0.2 – Overload Relay (NC) 🔹 Required Outputs (PLC OUTPUT) Q0.0 – Main Contactor (MC) Q0.1 – Star Contactor (SC) Q0.2 – Delta Contactor (DC) 🔹 Timer T1 – Star to Delta Timer (ON Delay, 5–10 sec) 🧩 RUNG-WISE LADDER LOGIC EXPLANATION 🔸 RUNG 1 – Start / Stop & Seal-in Circuit START (I0.0) press karte hi Main Contactor (Q0.0) ON ho jata hai Aur self-hold / latch ban jata hai. ➡ STOP ya Overload aate hi circuit OFF. 🔸 RUNG 2 – Star Contactor Control Jab Main Contactor ON hota hai aur Timer T1 complete nahi hua, tab tak Star Contactor (Q0.1) ON rehta hai. 👉 Motor STAR connection me run karti hai. 🔸 RUNG 3 – Timer Operation Jaise hi Main Contactor ON hota hai, Timer T1 start ho jata hai (for example 7 sec). ⏱️ Timer ka kaam: STAR se DELTA shift ka delay dena. 🔸 RUNG 4 – Delta Contactor Control Jab Timer T1 complete ho jata hai, aur Star Contactor OFF ho jata hai, tab Delta Contactor (Q0.2) ON hota hai. 👉 Motor DELTA connection me full speed pe chalti hai. 🔸 INTERLOCK LOGIC (MOST IMPORTANT) 🚫 Star aur Delta kabhi bhi ek sath ON nahi hone chahiye Iske liye: Star rung me Delta ka NC contact Delta rung me Star ka NC contact Lagaya jata hai
