Cutting mill CM 120M (VIBROTECHNIK)

See more: https://vt-spb.ru/catalog/dlya_droble... Cutting mills are designed to comminute fiber, polymer and plant materials. In cutting mills, comminution occurs by means of cutting – shear strains of material particles between rotor blades and a housing. The grain size of the comminuted product is regulated by the openings in the discharge grate and the physical properties of the material. Loading shaft dimensions – 60х80 mm Maximum initial material size – 50 mm Size of discharge grate openings – 0,8-20 mm Comminuted product particle size when 0,8 mm grate is used 90% 0,5 Maximum output – 2-100 kg/hour Electric motor power – 1,5 / 1,1 kW 50 Hz supply voltage – 220 / 380 V Rotor – 1500 rpm Overall dimensions 500х380х685 mm (Length x Width x Height) Weight – 48 kg Material of blades – tool steel AISI 01, DIN 150Cr14, AISI 5135 Hardness of blades – 40-45 HRc
