Student training aid for the connections required to wire a lighting circuit using the 3 plate loop-in method. Video explains the connection required within 2 gang switch and a 2 way switch to make it 2 way switching. The circuit is wired in twin and CPC cables (twin and earth cable) and 3 core and CPC cables in this wiring diagram for the circuit. This video will show learners how to connect up 2 gang light switch and a one gang 2 way light switch for the control of a downstairs light and an upstairs lights 2 way switched but this time they are all on the same circuit fuse. This method of wiring to the 2 gang switch means both the downstairs lighting circuit and the landing light are on the same fuse or MCB. this means that when you pull or operate just one fuse you will isolate all the conductor inside the 2 gang switch. How to wire up a 2 gang switch - this wiring diagram will help you understand the connection requires at both the 2 gang and 2 way switches. 🔔 Subscribe for more free electrical training videos https://youtube.com/c/GSHElectrical?s... ☑️ Link below is to the images used in the series of videos using a 2 gang switch https://1drv.ms/b/s!As2jEnZePpD0igH8i... 🔵 Wiring Diagrams for Lighting and Motor Circuits • Wiring Diagrams for Lighting and Motor Cir... == 🕐 Time Stamps - Cut to the action 🕕 == 00:00 - Downstairs and first floor landing light on the same circuit fuse 00:24 - Download the handout 01:18 - 2 MCB's required for isolation 02:17 - Frist cable from the consumer unit to the ground floor light 02:58 - Connections in a ceiling rose and pendant 04:03 - Twin and CPC cable (twin and earth) 04:53 - Bring a 3 core cable from the light to the 2 gang switch 05:22 - Black or grey and neutral... 06:18 - Adding our 3 core and CPC from the light to the 2 gang switch 07:11 - What to do with our neutral 07:52 - Wago 221 or Insure connectors 09:05 - Different method for 2 way switching 09:37 - Finding a line connection for out common 10:29 - L1 and L2 to L1 and L2 12:15 - Bring the neutral through the switch 13:08 - Cable from the light to the 1 gang 2 way switch 15:21 - One MCB or fuse turns of the circuit 15:49 - Hint at adding an outside light Videos are training aids for City and Guilds (C and G) and EAL courses Level 1, 2, 3 plus AM2, AM2S and AM2E. You can follow me day by day on Facebook, Instagram, Twitter and TikTok lookout for "GSH Electrical”. ▶️ FACEBOOK / gshelectrical ▶️ INSTAGRAM / brihzmraygdtmjmdb9lunqodmevqsbddki3qpq0 ▶️ TWITTER / gsh_electrical ▶️ TikTok https://vm.tiktok.com/ZMRBLFdhe/ #GSHElectrical #Electricaltrainingvideos #wiring #wiringdiagram #lighting
