Avant attachments: Multi function drive unit

The new multi function drive unit replaces the earlier auger drive unit A21100. Avant auger drills and screw pile adapter are mounted on it as always, but thanks to the new design the multi function drive unit can also be fitted with various new attachments: concrete mixing drum, screw cone log splitter, screening drum, cable/hose reel, carousel broom and rotary hoe. In addition, there is a 90 degree angle adapter available on which the drive unit can be mounted. It turns the drive unit 90° to the left. This means that for instance the carousel broom sweeps on the left side of the loader, and the cable/hose reel is crosswise to the loader and winds the cable longitudinally (in parallel to the loader). Torque 1355 Nm SCREW CONE LOG SPLITTER Log splitter with a conical splitting screw Splitting screw equipped with a replaceable tip Also equipped with a log holder bar which prevents the log from rotating during splitting Weight 30 kg CONCRETE MIXING DRUM CABLE/HOSE REEL SCREENING DRUM Intended for screening of soil, gravel and sand Screening sieve with 50x50 mm holes – included also a separate 22x22 mm sieve, which is bolted on the drum when finer screening is required ROTARY HOE For small scale soil cultivating Equipped with two knife type blades CAROUSEL BROOM Same Ø 1000 mm broom as on A2971 Carousel broom Replacebable brush A32698 Weight 67 kg Can also be mounted on the A37323 Angle adapter 90° sweeps on the left side of the loader ANGLE ADAPTER 90° Turns the multi function drive unit to point to the left SCREW PILE ADAPTER With Avant and multi function drive unit you can install screw piles in the ground quickly and easily. The screw pile adapter mounts on the multi function drive unit and fits on Ø 60 mm screw piles. The adapter can be mounted on all Avant auger drives – the correct type of the auger drive depends on torque required: how hard the ground is, and dimensions of the screw pile. Remember to subscribe to our channel for more similar content! Follow us on: Instagram@avantsuomi Facebook Avant Suomi LinkedIn Avant Tecno
