FlyRoller - Laser system with conveyor for brake discs - LASIT

About one year ago we started the project to realize a laser marker with precise technical parameters and that could have been integrated into a massive production chain. Today we know this machine as FlyRoller for laser marking DataMatrix codes, that can be customized ad hoc to meet the criteria of efficiency and reliability required by a customer. The machine consists of a marking cabin and a motorized roller conveyor. The cabin is equipped with Y and Z axes with vision system, while the roller conveyor works with two robots: one loading the incoming disk and the other picking it up after marking and check. Once the sensors have detected the presence of the disk, the conveyor belts move until the introduction of the piece into the cabin. At this point the sensors detect the position of the pieces and the Feed separator regulates the entry into the cabin of only one component at a time. When the disk enters the marking cabin it is blocked by a pneumatic system and framed by a side camera connected to the Software. This has a double function: firstly, it allows the correct positioning of the laser and direction of the spot. Subsequently, once the laser marking of DataMatrix has been completed, the result is checked: if the quality is lower than the one set, the machine automatically remarks on the brake disc oriented at a previously established angle. In this way there is no risk of introducing discs with illegible or more easily damaged markings into the complex production process. We have equipped the machine with a lift which lifts the disc from the snare drum and puts it in the entry position to the next step in the chain. Before the perfectly marked disc leaves the Flyroller, the marker checks its positioning thanks to two vision systems. Once lifted, the piece is framed by the first camera from above: if the position is not the one set, this is automatically corrected by rotating the disk. 💥 Subscribe our channel for other amazing news and technologies ➡ https://www.youtube.com/channel/UCApg... 💡 Visit our website and discover all the opportunities to improve your productivity: https://www.lasitlaser.com/laser-mark... 🔹 The main feature of the TowerMark X is an innovative system that moves the laser along the X and Z axes, allowing for the marking of individual pieces in all different sizes as well as – and especially – pallets as long as 600 mm x 170 mm. 🔹 This is done in such a way so as to not obstruct the work area of the marking machine at all and to utilize all available space. Facebook ➡️ https://bit.ly/3gKnlDH Linkedin ➡️ https://bit.ly/3uSSw83 #lasermarkingmachine #automation #lasit
