Export Revit Sheets to AutoCAD Model Space with Correct Scale (3 Methods)

Download the Plugin: https://mlabsolution.com/export-sheet... Stop struggling with scaling issues when exporting from Revit! In this tutorial, I demonstrate how to export Revit sheets directly into AutoCAD Model Space while maintaining accurate dimensions. Whether you need a 1:1 layout or real-world geometry scales, this tool handles it automatically. In this video, you will learn: 3 Export Methods: From 1:1 Layout Scale to Sheet-Ratio-based scaling. The "As Indicated" Fix: How to handle sheets with multiple scales (e.g., 1:50 and 1:100). AutoCAD Integration: Tips for Batch Printing and Page Setup for a seamless workflow. Important Notes: Close AutoCAD before running the command to avoid conflicts. Let the plugin run undisturbed for the best results. Timestamps (Video Chapters) 0:00 Introduction to Model Space Export 0:08 Option 1: Exporting with 1:1 Layout Scale 1:01 Analyzing Scale Discrepancies (Measure vs. Dimension) 1:14 Option 2: Scaling Based on Sheet Ratio 1:30 How to Handle "As Indicated" Scale Values 2:02 Verifying Real-World Dimensions in CAD 2:16 Troubleshooting: Batch Printing & Missing Drawings 3:38 Option 3: Smart Scaling for Multiple Scale Views 3:50 Example: Handling 1:50 and 1:100 Scales
