How to use Intersection Curve in SolidWorks.

SolidWorks Tips & Tricks. How to use "Intersection Curve" in SolidWorks. Intersection Curve tool in Solidworks sometimes can be very useful tool to obtain intersections between 3D or 2D geometries. Intersection Curve opens a sketch and creates a sketched curve at the following kinds of intersections: -A plane and a surface or a model face. -Two surfaces. -A surface and a model face. -A plane and the entire part. -A surface and the entire part. You can use the resulting sketched intersection curve in the same way that you use any sketched curve, including the following tasks: -Measure thickness at various cross sections of a part. -Create sweep paths that represent the intersection of a plane and the part. -Make sections out of imported solids to create parametric parts. To use the sketched curve to extrude a feature, the sketch that opens must be a 2D sketch. Other tasks can be performed using a 3D sketch. -To open a 2D sketch, select the plane first then click Intersection Curve. -To open a 3D sketch, click Intersection Curve first then select the plane. #solidworks #cad #cam #cnc
