Preparation for grouting of Post Tension work/Grouting of tendon

Tests-Fluidity test & Compressive strength test Post Tensioning Systems • DYWIDAG Post-Tensioning System - Multiple Anchorages (MA) tendon • UPS Systems - Flat Anchorage (FA) tendon Proposed grout mix • Cement in standard 50kg package (Ordinary Portland Cement) • Water = 0.44 x 50kg = 22 kg= 22 liters • Admixture = 0.4% weight of cement (50 kg) = 200gm StoCrete AEG • Mixing sequence = water – additive – cement • Min mixing time = 3-5 min Fluidity test • Fluidity test will be executed by means of a flow cone. • Flow time is measured with a stop watch. • It is the measurement of time for 1 liter grout takes to completely flow out of the cone. • It is carried out immediate after mixing. • The flow time should be between 10 to 25 seconds. Compressive strength test • 6 test cubes of 100 x 100 x 100 mm shall be prepared per grouting session. • After 24 hours, remove cubes from mould and store in the water storage tank. • Average compressive strength of 3 cubes shall be tested at 7 and 28 days. • According to specification, average compressive strength of 3 cubes shall be: 7 days: minimum of 21 N/mm2 28 days: minimum of 30 N/mm2 #rebar #Posttensiontendon #columnrebar #shortvideo #video #instagram #love #instagood #trending #tiktok #like #reels #viral #music #india #follow #youtube #dance #short #instavideo #viralpost #funny #shortfilm #shortvideos #shortstories #comedy #cute #viralvideos #viralvideo #photography #videography #instadaily #bhfyp #construction #civilworks #civilengineering #engineering #concretestructure #shortvideo #video #instagram #love #instagood #trending #tiktok #like #reels #viral #music #india #follow #youtube #dance #short #instavideo #viralpost #funny #shortfilm #shortvideos #shortstories #comedy #cute #viralvideos #viralvideo #photography #videography #instadaily #bhfyp #construction #civilworks #civilengineering #engineering #concretestructure
