[Sensor Modules | Security] Alcohol Digital Sensor BM22S3421-1 скачать в хорошем качестве

[Sensor Modules | Security] Alcohol Digital Sensor BM22S3421-1

📌Alcohol Digital Sensor BM22S3421-1 💻More Information: https://www.bestmodulescorp.com/BM22S... 00:00 00:14 Demo Operation 00:15 00:26 Alcohol Digital Sensor BM22S3421-1 00:27 00:47 Product Features 00:48 01:00 Pin Description 01:01 01:06 Required Materials 01:07 01:29 Getting Started 01:30 01:39 Getting Started -Installation 01:40 01:54 Getting Started -Arduino library 01:55 02:11 Demo Operation-Warm-up time 02:12 02:45 Demo Operation- Alcohol detection 02:46 02:50 www.BestModulesCorp.com ✒Description BM22S3421-1 is an alcohol digital sensor that is used to detect concentration of alcohol. The product provides two output modes: STATUS and UART. You can get the alarm status through STATUS pin or UART interface. ▓How to detect alcohol concentration and trigger an alarm? There are four levels to range alcohol concentration from 1 to 4 (low to high). The current concentration level, AD value, and alarm status can be outputted via UART interface every second. You can also monitor the STATUS pin to determine whether the alarm has been triggered. The voltage level turns high when alarming. ▓Configure alarm threshold and exit alarm condition You can use commands to configure the alarm level and alarm exit level. →Alarm (default: level 3): when the product detects that the alcohol concentration in the environment has reached the alarm level for more than 3 seconds, the alarm will be triggered. →Exit alarm level (default: level 1): when the product detects that the alcohol concentration in the environment has reached the alarm exit level for more than 3 seconds, it exits alarm condition. ⬥ Refer to 'UART Communication Instruction Set Summary' chapter in the datasheet for more details. ▓How to determine the concentration level corresponding to the alarm threshold? 1. Place the product in the environment with the alcohol concentration that you desire for alarm. 2. Read the concentration level via UART interface. 3. And then configure this level as the alarm level. For example, if you desire to trigger the alarm at a 350ppm alcohol concentration, place the product in an environment with a 350ppm concentration. Read the output concentration of 350ppm as level 4 via UART interface, and then configure level 4 as the alarm level. ✒Features ◆Sensor type: MEMS ◆Operating voltage: 3V~5V ◆Operating current: 17mA @3.3V ◆Detect alcohol (C2H5OH) concentration in the environment ◆Detection range: 0~400ppm →Concentration level: 1~4 (default alarm level: 3) ◆Output mode: UART (baud rate: 9600bps) / STATUS ◆Factory calibration ◆Warm-up time: 180 seconds (default) ◆Dimension: 24 x 20 x 20 mm ◆Net weight: 7.8g 🏢 Best modules corp. 🔗NO. 3, Creation Rd. II, Science Park, Hsinchu 30077, Taiwan 🤝service@bestmodulescorp.com #SensorModules #AlcoholSensor #DetectionModule #Modules #AlcoholDetector #Detector #sensor #BMduino-Shield #Shield #Arduino #BMduino #Caca愛吃好心情 #Caca愛跟風 #Jessicaca256 #JessicaChiang #Jessica.ca.25 #Ca滋Ca滋卡卡滋
