Homemade PCB milling machine

For those asking for the plans, BOM, etc, I merged all files in a 7-Zip file so you can download it. It's included: the complete 3D model (in Solidworks format, main file is CNC.SLDASM) the 2D drawings used to machine the parts (if it doesn't have a 2D drawing, it's a laser cut part, so there's only the 2D DXF file used by the laser mahines) some pictures from the assembly a powerpoint presentation about the project Note that all material is in portuguese. It shouldn't be a big deal, since you can check all data and dimensions on the 3d model. It was a graduation project, so if you have interest send a message and I'll send you the paper explaining the design choices, calculations, etc. But it's in portuguese as well. A few notes that I remenber: A couple of hole were modeled with the wrong diameter, but I don't remember which ones anymore. I wouldn't use countersink bolts if I had to rebuild this machine. It gave me a lot of trouble when aligning the linear slides. If you have any further questions feel free to ask. Link for download: http://www.3dmacro.net/public/CNC_Mil...
