SDI VtoF - Calibrate Values A, B, C

Starting with “Scale A”, determine the point at which the grid line intersects the perforation. The grid number at that point is the calibration value. For Scale A, the value is 542. Flipping the image over and examining the value from the opposite side of the perforation helps to ensure that an accurate value is determined. Move to “Scale B” and step through the process in the same way, once again determining the intersect point of the grid as it crosses the perforation. It’s critical to carefully determine these values as doing so will ensure accurate Top of Form printing. For Scale B, the calibration value is 412. Flipping the image and viewing from the opposite side of the perforation confirms the 412 value. With Scale C, again examine the intersect point to determine the calibration value, in this case, 524. Viewing the image from the opposite side helps confirm the 524 number. With these values documented, we now can enter the calibration values into the Calibration Entry Table.
