Frisian Spring

GENERAL PARTICULARS Name Frisian Spring Flag Netherlands Call-sign PHII IMO no. 9367774 Port of registry Sneek Managers / Operator Boomsma Shipping BV Registered Owner Scheepvaartond. M/S Frisian Spring CV Classification society Lloyds Register 100 A1 LMC UMS, ice class 1B General Cargo Ship Year of build / Shipyard 2007; Peters Shipyards BV, Kampen VESSELS PARTICULARS Length overall 118,90 meter Length bpp 111,69 meter Breadth extreme 13,45 meter Draft max. summer 6,08 meter Depth 9,10 meter Gross tonnage 4.087 Nett tonnage 1.747 Deadweight 6.582 mt Airdraft in ballast 25 meter DWCC Summer 6.100 mt (full bunkers) 6.310 mt (half bunkers) DWCC Winter 5.910 mt (full bunkers) 6.120 mt (half bunkers) Immersion at max. draft 14,84 t/cm COMMUNICATION Mobile phone YES E-mail YES GMDSS fitted YES MMSI 246571000 Inm. C YES Sat. phone YES HOLDS PARTICULARS No. of holds / hatches 2 hold / 2 hatch Type of hatch Pontoon covers (13 pieces) Hold dimension (lxwxh) 18,70 x 11,20 x 9,00 Hold 1 Hold dimension (lxwxh) 59,90 x 11,20 x 9,00 Hold 2 Hatch dimension (lxw) 18,70 x 11,20 Hold 1 Hatch dimension (lxw) 59,90 x 11,20 Hold 2 Box shaped YES, 100% box Hold capacity 7.923 m³ / 279.798 ft³ Grain bulkhead 3 pieces in hold 2, for 9 positions including storage positions Top of hatchcoaming 10,00 meter above baseline Tanktop strenght 15 mt/m² Hatchcover strenght 1,6 mt/m² Ventilation 6 air changes / hour TECHNICAL PARTICULARS Main Engine Wärtsila 6L26A2 2040 kW Speed 10 knots loaded and 11,5 knots in ballast Fuel Consumption 9,4 mt per day at sea 0,5 m³ per day in port Fuel Type IFO 380 for Main Engine MGO for Aux. Eng Bowthruster fitted YES, 280 kW Bunkercapacity 333 m³ IFO 380 and 37 m³ MGO Freshwater capacity 42 m³ Ballastwater capacity 2.378 m³
