Retractable tool holder for lathe - Episode 12 - Final

This is the final episode of the tool holder. I will make the mover interacting with the eccentric and attach the handle. Complete drawings for this project are available at my Google-drive: https://drive.google.com/drive/folder... In this video I use: Schaublin SV-51 (1955) Milling machine Chapters: 00:00:00 Opening animation 00:03:41 Introduction 00:04:52 Milling material to size 00:16:17 More milling to too small size 00:24:22 Even more milling with minor mistake 00:34:25 Milling a square hole 00:41:11 Milling cosmetic features 00:48:48 Setting scales using the Haimer 00:52:07 Drilling two holes for M4 cap screws 00:54:21 Milling recesses for M4 cap screws 00:55:26 Cutting the workpiece off with a slitting saw 00:59:16 Drilling and tapping a M6 thread for the handle 01:03:44 Attaching the handle and some testing 01:05:15 Some advice wanted 01:06:04 Conclusion 01:09:52 End credits
