Mains Ramped PLL Solid State Tesla Coil

This is my first mains ramped SSTC project. 30 gauge 8 X 4.5 inch coil 260n Half Bridge 4046 PLL IC MOSFET drivers are UCC37322's Primary resonant cap 2 X Phillips 2kv 7n5 caps in parallel. Staccato is wards circuit The SCR is a BT151 120-140 a/c from the auto transformer - half wave rectified. Thanks to Tesla Explorer for helping me get vacuum tube arcs, without a tube! and for sharing his brain, circuit, and sense of humour. Man we have some laughs making this stuff. Thanks for watching Cheers Deeds I joined another short run on the end. :D
