Getting Volume Reports in Carlson Takeoff

Learn more at carlsonsw.com Presented by Jim Carlson, 2014 MOVIE TIMELINE: Part 1: 0:00 - Carlson Takeoff R7 - Project Checklist - Start to Finish Steps to Calculate Volumes 1. Define Layer Targets/Subase/Materials 2. Boundary Polyline 3. Make Existing Surface 4. Make Design Surface 5. Calculate Volumes Part 2: 1:30 - Carlson Takeoff R7 - Four Methods to Calculate Volumes 1. Straight Cut/Fill 2. With Subbase 3. With Areas of Interest 4. With Topsoil Removal/Replacement Part 3: 3:00 - Carlson Takeoff R7 - Display Drop Down Options 1. Toggle On/Off Cut/Fill Map & Labels 2. Toggle On/Off Existing Layers Category 3. Toggle On/Off Design Layers Category 4. Toggle On/Off Other Layers Category Part 4: 4:30 - Review Drawn 3DPolylines Fault or Barrier Lines & Contour the Design Layers Category to Check Accuracy of Design Surface 1. Edit-Assign Contour Elevations 2. Re-Contour the Design Surface using Design Contour Toggle On/Off 3. Review Design Contours to confirm they duplicate given contours in original DWG Part 5: 6:45 - Prepare to do Method 1 Calculate Volumes Straight Cut/Fill by removing all polyline perimeters for Methods 2 through 4 1. Remove Topsoil Removal/Replacement Polylines 2. Untag Areas of Interest Polylines 3. Set New Boundary Polyline by first clearing existing selected boundary polyline(s) 4. Remove all Subgrade treatment by toggling off in Define Layer Target/Subgrade/Material, Design Category, "Adjust Target Surface by Depth" Toggle off "Adjust Target Surface by Depth" for all Design Target Layers with Subgrade treatment, Save Example-1.trg Target Layer State for Existing/Design/Other Categories Part 6: 9:05 - Method 1 - Calculate Volumes Straight Cut/Fill 1. Project Checklist - Steps 1 and 2 Done 2. Toggle On Step 3 Make Existing Surface 3. Toggle On Step 4 Make Design Surface 4. Toggle On Last Step 5 Calculate Volumes 5. Review & Compare Cut/Fill Earthwork Reported Results 6. Check Existing & Design Surfaces using Quick Profile from Surfaces Part 7: 11:40 - Method 2 - Calculate Volumes with Subgrade 1. Define Layer/Material/Subgrade and toggle back On all subgrade areas pre-defined and save Target Layers w/subgrades 2. Project Checklist - Steps 1 and 2 Done 3. Hatch Subgrade Areas/Erase Hatch Subgrade Areas 4. Toggle On Step 3 Make Existing Surface 5. Toggle On Step 4 Make Design Surface 6. Toggle On Last Step 5 Calculate Volumes with Subgrades 7. Review & Compare Cut/Fill Earthwork Reported Results with Subgrades 8. Check Existing & Design Surfaces using Quick Profile from Surfaces with Subgrades Part 8: 17:00 - Method 3 - Areas of Interest 1. Isolate Layers & Layer Control to toggle On only layers for subgrades and pond/pad perimeter closed polylines 2. Areas of Interest - Tag and Name Areas of Interest closed polylines 3. Project Checklist - Steps 1, 2, 3 and 4 Done 4. Toggle On Last Step 5 Calculate Volumes with Subgrades & Areas of Interest 5. Review & Compare Cut/Fill Earthwork Reported Results with Subgrades & Areas of Interest Part 9: 22:25 - Method 4 - Topsoil Removal/Replacement 1. Isolate Layers & Layer Control to toggle On only layers for subgrades and perimeter closed polylines 2. Define Topsoil Removal & Replacement default (global) depths 3. Set Topsoil Removal Polylines and pick the perimeter polyline 4. Set Topsoil Replacement Polylines and pick the inclusion perimeter polyline and exclusion subgrade polylines 5. Hatch Topsoil Replacement Areas/Erase Topsoil Replacement Areas 6. Project Checklist - Steps 1 and 2 Done 7. Toggle On Step 3 Make Existing Surface 8. Toggle On Step 4 Make Design Surface 9. Toggle On Last Step 5 Calculate Volumes, Subgrades with Topsoil Removal/Replacement 10. Review & Compare Cut/Fill Earthwork Reported Results with Subgrades, Areas of Interest and Topsoil Removal/Replacement Part 10: 29:00 - Toggle On Cut/Fill Labels & Color Map and End Example-1 Training Movie 1. Toggle On Cut/Fill Labels & Color Map 2. Review Cut/Fill Labels for Existing, Design and Cut or Fill Labels 3. End movie showing how to produce outputting volume reports for the 4 Methods in Carlson Takeoff R7 for computing volumes 1. Standard Cut/Fill 2. Cut/Fill with Subgrades 3. Cut/Fill with Subgrades & Areas of Interest 4. Cut/Fill with Subgrades, Areas of Interest and Topsoil Removal/Replacement
