Segment Routing | Mapping Server | Internetworking between LDP and Segment Routing

Segment Routing | Mapping Server | Internetworking between LDP and Segment Routing IOS-XR | ASR9000 | IOS-XE ========================================================= The mapping server is a key component of the interworking between LDP and segment routing. It enables SR-capable nodes to interwork with LDP nodes. The mapping server advertises Prefix-to-SID mappings in IGP on behalf of other non-SR-capable nodes. =========================================================== P1 [ Mapping Server-1] segment-routing mpls ! set-attributes address-family ipv4 sr-label-preferred exit-address-family ! global-block 16000 17000 ! connected-prefix-sid-map address-family ipv4 11.11.11.11/32 index 100 range 1 exit-address-family ! ! mapping-server ! prefix-sid-map address-family ipv4 1.1.1.1/32 index 1 range 1 2.2.2.2/32 index 2 range 1 exit-address-family ! router isis CORE net 49.1920.1680.0011.00 is-type level-2-only metric-style wide segment-routing mpls segment-routing prefix-sid-map advertise-local fast-reroute per-prefix level-2 all fast-reroute ti-lfa level-2 P2 [ Mapping Server 2] segment-routing global-block 16000 17000 mapping-server prefix-sid-map address-family ipv4 1.1.1.1/32 1 2.2.2.2/32 2 RP/0/0/CPU0:P2#sh running-config router isis Tue Jan 17 20:13:32.199 UTC router isis CORE is-type level-2-only net 49.1920.1680.0002.00 address-family ipv4 unicast metric-style wide segment-routing mpls sr-prefer segment-routing prefix-sid-map advertise-local
