QL Standard Magnetic Solution, 275 kg capacity

This video shows one of the standard magnetic gripping solutions. The max capacity of this gripper is 275 kg. This unique integrated mechanical, electrical, pneumatic swivel enables continuous rotation of the end effector. Easy to use, thanks to outstanding responsiveness, regardless of load weight. Exceptional safety is achieved using our intelligent control systems. For more Quick-Lift gripping options visit, https://www.quickliftsystems.com/inte... or to discuss a custom solution email sales@quickliftsystems.com Lifting capacity Maximum lifting capacity varies depending on the shape of the object to be lifted. Note: The lifting capacity is reduced when the center of gravity of the object to be lifted is eccentric. Steel plate Thickness 25 mm 300 kg Thickness 20 mm 270 kg Thickness 15 mm 210 kg Thickness 10 mm 150 kg Note that magnetism under the steel plates less than 25 mm can occur. Round steel Ø 60-250 mm, Maximum length 1500 mm Maximum weight 135 kg Air supply Clean dry air, filtered, pressure 6.0 -8.0 bar is required Temperature Maximum temperature of lifting object 50° C. Safety For each lifting maneuver, the control unit performs 3 internal security tests before the load can be lifted or handled. Are a quick and easy process, which does not disturb the operator's productivity. Other The tiltable magnetic gripper is operated with the lower buttons on the handle. Handle with 5/2 pneumatic valve and swivel included. No arm or rail system is included. Options Quick-coupling, Quick-coupling pin, and flange to connect end effector with Quick-Lift control unit. End Effecto's weight: 21 kg / 46 lbs
