C-More EA9 HMI Series Headless RHMI Setup Screens!

Stop struggling with the C-More EA9 headless setup! Master RHMI configuration via a USB connection and unlock all the setup screen features you need. We will now look at the cmore ea9 hmi setup screens. The C-more headless EA9-RHMI is programmed using the C-more Programming Software, EA9-PGMSW. The developed project is transferred from the PC to the HMI via a USB or Ethernet connection. Previously, we used the Ethernet connection to establish communication. We will use the USB connection to communicate, save the program, and review the Headless C-more setup screens. Let's get started. 📖 FULL WRITTEN TUTORIAL + DOWNLOADS https://accautomation.ca/c-more-ea9-h... ⏱️ TIMESTAMPS 0:00 - Introduction to C-More EA9 Headless RHMI Setup 0:32 - Hardware Connection and USB Setup 1:12 - Setup Screen Connection Status 1:25 - Device Manager and USB Driver Installation 2:08 - Reading Panel and Connecting 2:34 - Panel Information and Main Menu Navigation 3:25 - USB Remote Setup and Panel Operation 3:49 - Information Tab - Hardware Details 4:21 - Settings Tab - Clock IP and Calibration 4:40 - Test Menu - Touchscreen LED and Comm Ports 5:10 - Memory Tab - Backup Restore and Reset Functions 5:41 - Wrap Up and Requirements Summary 📚 WHAT YOU'LL LEARN ✅ How to connect C-More EA9 headless RHMI via USB for setup access ✅ Navigate all setup screen tabs: Information, Settings, Test, and Memory ✅ Install and troubleshoot EA9 USB drivers in Device Manager ✅ Backup, restore, and reset HMI memory and system settings ✅ Test touchscreen, LEDs, communication ports, and audio features 🔗 MORE RESOURCES ▶ Series: https://accautomation.ca/series/c-mor... ▶ PLC Beginners Guide: https://accautomation.ca/programming/... ▶ Free eBooks: https://accautomation.ca (subscribe for download) 🛒 RECOMMENDED HARDWARE ▶ Training Kits: https://accautomation.ca/series/c-mor... 💬 Questions? Drop a comment below. 🔔 New tutorials every Monday — Subscribe and hit the bell! #PLC #HMI #IndustrialAutomation #LadderLogic #AutomationDirect #PLCProgramming #ACCAutomation There are several reasons that we are using the EA9-T10CL C-More HMI Panel. Here are a few: • Touch screen display (LCD) 280 NITS display brightness • 10.4" diagonal color TFT (Thin Film Transistor) • Analog resistive (1024 X 1024) touch screen allowing unlimited touch areas • EA9-PGMSW programming software • 800 x 600-pixel display • 64K colors • 50,000-hour average backlight half-life • USB port B (program/download) and USB port A (USB device options) • Ethernet 10/100 Base-T port (program/download & PLC communication • Remote Internet Access • Serial PLC interface (RS-232/422/485) • One built-in SD memory card slot • 12–24 VDC powered (18W), 110VAC power adapter (optional) • Audio Line Out, stereo - requires amplifier and speaker(s) • 26MB project memory • Data logging • 0 to 50°C [32 to 122°F] operating temperature range • NEMA 4/4X, IP65 compliant when mounted correctly, indoor use only • Slim design saves panel space • UL, cUL & CE agency approvals • 2-year warranty from date of purchase Regards, Garry ACC Automation https://www.accautomation.ca
