Elytra Filament Pavilion at the Victoria and Albert Museum

Elytra Filament Pavilion is the outcome of four years of ground-breaking research on the integration of architecture, engineering and biomimicry principles. The project explores how biological fibre systems can be transferred to architecture. The 200m² pavilion structure is inspired by lightweight construction principles found in nature – the fibrous structures of the forewing shells of flying beetles known as elytra. Elytra’s components have been fabricated by a robot at the University of Stuttgart and assembled on site in the V&A’s John Madejski Garden. The pavilion will grow and change its configuration over the course of the V&A Engineering Season in response to anonymous data on how visitors use and move under the canopy, fabricated live in the garden by a Kuka robot. Experimental architect Achim Menges with Moritz Dörstelmann, structural engineer Jan Knippers and climate engineer Thomas Auer have pioneered a unique robotic fabrication technique developed by the University of Stuttgart’s Institute of Computational Design (ICD) and Institute of Building Structures and Structural Design (ITKE). This technique, developed by the team over several years of prior research, involves a novel way of winding composite materials by a robot arm. This innovative winding method has been designed to harness the material properties of carbon fibres to give them strength as woven structural components. A series of these individual cell-like modules have been used to create the pavilion’s distinctive shape. This production method integrates the processes of design, engineering and making and explores the impact of emerging computational and robotic technologies on these disciplines. Elytra’s canopy is made up of 40 hexagonal component cells. On average they weigh 45kg each and take an average of three hours to make. Source Victoria and Albert Museum. Info project https://goo.gl/NekbZg A As Architecture - Discover Architecture http://aasarchitecture.com/
