DANOBAT Roughing Cell

For required high productivity, coupling threading may be done on the CL and CIH range of machines. Couple threading may be done in a single clamping on the CIH range of machines. Main features are as follows: Indexing capability in order to perform coupling quality (single set-up), CIH model. Headstocks prepared for assembly of hydraulic indexing chuck to finish the coupling in a single set up, CIH model. Rigid design capable of performing not only threading but also the roughing of PREMIUM couplings. Heavy duty vertical axis turret prepared for high pressure through tool coolant. Symmetrical distribution of guideways balancing cutting forces for higher accuracy. Main motor power up to 100 kW (134 Hp), depending on model. Tooling solutions for "pushing", cutting threads inwards, or "pulling", cutting threads outwards, facilitating optimal chip evacuation and protecting the threaded area. Available with Fanuc, Siemens or Fagor control system. Different designs of coupling handling systems may also be integrated along with the lathes for single source delivery on a turnkey basis.
