VB46-B121F2A | Double-Side Prototype PCB printed Universal Circuit Board Veroboard 4x6cm dotted

For product details & purchase click on the following link: https://www.arduinopak.com/Prd_Detail... Double-Side Prototype PCB Universal Circuit Board Veroboard 4x6cm dotted 1.Quality Material: These prototyping board are made of high quality FR-4 glass fiber PCB thick and sturdy and they do not melt when solder is applied. Top and bottom side are identical copper layers 2.Sturdy and Easy to use: All the boards are thick and double sided. The plated holes are tinned and very solid which makes it very easy to solder components PACKAGE INCLUDES: PCB, 4 x 6 cm Universal Prototype Board KEY FEATURES OF PCB 4 X 6 CM UNIVERSAL PROTOTYPE BOARD: Size: 4 x 6 cm outside dimensions 1.6mm (0.64?) thickness FR-4 double-sided construction with green solder mask Holes on 2.54mm (0.1?) centers in grid pattern with alphanumeric grid marked along edges of the board. Holes are plated through with same pad pattern on both sides of the board. Edge solder pads are on 2.54mm (0.1?) centers HASL (SnPb) plating over copper for best solderability These boards are useful for permanently mounting components and wires via soldering when a project is put into permanent use. Some circuits with high energy or high frequency such as DC-DC converters or high power MOSFETs need to be prototyped on boards of this type rather than using solderless breadboards since the components need to be placed closely together with robust connections that can handle heavy current transients. Please Don't Forget Like & Subscribe.🧡 This video only showcase a Megatronics product, not a learning tutorial. Megatronics.pk is an Electronics & Electrical parts supplier for students, hobbyists, industry and professionals in Pakistan, we have a variety of Electronics modules, sensors, mechanical parts, discrete electronics components, robotics and many more visit our website https://www.megatronics.pk to see all our exciting listings. Follow us on Facebook:   / megatronics.pk   Daraz shop 1: https://www.daraz.pk/shop/megatronics... 2: https://www.daraz.pk/shop/arduinopakcom Contact: University road Gul haji plaza 4th Floor # 414B Peshawar, Pakistan. Tel: +923459056515, +92915711395
