PETamentor 2 SS Spooler - Gearbox Upgrade - Assembly

Here's the latest upgrade to our PETamentor 2 SS. I've integrated a geared spooler, and its design has been thought to stand up to all tests. It's part of the latest batch of improvements to the PETamentor 2. The bearing cutter is also to be updated. Everything you need, available now on our website : https://petamentor2.com/ Join us on our Facebook group !   / 594548605536945   Parts list and assembly instructions, in chronological order : 01 - Your Board 02 - Frame_Rear.stl 03 - 608zz Bearing (x2) 04 - M3 nut (x4) 05 - Countersunk wood screw Ø4x16 (x3) You absolutely must attach it to the board at this point. 06 - Frame_Front.stl 07 - 608zz Bearing (x2) 08 - M8x100 countersunk screw (x1) 09 - M8x60 countersunk screw (x1) 10 - Spacers_for_B&C.stl 11 - M3x10 screw (x4) 12 - Countersunk wood screw Ø4x16 (x4) 13 - The 7RPM DC Motor 14 - M3x6 screw (x2) 6mm To avoid touching the motor's internal gears --- (Edit : I'm going to remove these 2 holes to avoid any breakage) 15 - M3x8 screw (x4) 16 - Gear_A.stl 17 - M3 nuts (x4) 18 - The 6mm Flange coupling 19 - M3x16 screw (x4) 20 - M3x3 needle screw (x1) 21 - Remove M8x100 screw 22 - M8 Washer (x1) 23 - Gear_B.STL 24 - Replace the M8x100 screw 25 - M8 Washer (x1) 26 - M8 nut (x1) 27 - Remove M8x60 screw 28 - M8 Washer (x1) 29 - Gear_C.STL 30 - Replace the M8x60 screw 31 - M8 Washer (x1) 32 - M8 nut (x1)
