Printed Circuit Board Preparation

Manufacture of high quality printed circuit boards requires validation of every batch produced. Test pieces from the board need to be extracted, and then mounted to support them during samples preparation. SamplKwick acrylic mounting compound is designed for rapid and effective encapsulation of PCB coupons. The PC-MET and PWB-MET accessories are designed for high volume labs, and where best repeatability and reproducibility is required. Watch this video to see how using these accessories, used with the EcoMet range of grinder-polishers, can improve productivity and provide excellent results in any PCB quality control laboratory. To purchase the accessories visit https://shop.buehler.com. To purchase the PC Wiring Board Accessory or the PW Small Hole Accessory click on ordering info in the main website (https://www.buehler.com/specialty-gri...) page to see the item numbers . Other consumables ideal for the sample preparation process of electronics (shown in video) include: · CarbiMet PSA (https://shop.buehler.com/silicon-carb...) – Quick grinding SiC papers that offer minimal surface damage · TexMet C (https://shop.buehler.com/texmet-c-2-7...) – Non-woven cloths offering medium to fine polishing when combined with diamond suspension · Metadi Supreme Suspension (http://www.buehler.com/diamond-suspen...) – Use the 3 µm diamond suspension for fine polishing samples when sprayed on polishing cloths · MicroCloth (https://shop.buehler.com/microcloth-f...) – Synthetic rayon cloth offering fine surface finish · MasterPrep (https://shop.buehler.com/masterprep-s...) – Alumina final polishing suspension to improve surface finish on many materials SamplKwick (http://www.buehler.com/acrylic-mounti...) - Acrylic mounting system that offers quick cure time and excellent wetting conditions. By dipping coupon in Acrylic liquid prior to potting, Buehler’s SamplKwick is able to wet and enter into smaller holes and recesses well, with ease offering good penetration and the edge retention needed for great electronics preparation. To reduce the viscosity of mixed acrylic, powder to liquid volume mixing ratio of 1:1 or 1.5:1 is preferable.
