Tutorial KDSI-SR-G | Cable entry system with split frame

Cable entries for every application! The inverse and modular KDSI-SR-G cable entry system offers maximum flexibility and time savings in terms of cable management for control cabinets, enclosures and machines, as well as the secure sealing of cables with and without connectors. The two-part screw frames enable service-friendly and flexible cable assembly from the outside to the inside. The screwless, horizontally latching frame halves lock positively into place using a dovetail solution and are equipped with a double, overlapping TPE seal. This ensures tightness in accordance with protection class IP66. The KDSI-SR-G cable entries fit standard cut-outs for 4-, 10-, 16- and 24-pin heavy-duty connectors.
