Pertici MC 400

3/4 CNC controlled axis X axis maximum travel (longitudinal): 4175 mm Y axis maximum travel (transversal): 500 mm Z axis maximum travel (vertical): 490 mm A axis maximum travel (only for models having rotating table): -90° ÷ +90° X Axis drive max speed: 90 m/min Y Axis drive max speed: 60 m/min Z Axis drive max speed: 60 m/min Rotating table drive max speed (if present): 90°/s Electrospindle power: 5,5 kW Electrospindle maximum speed: 18000 rpm Tool store (if present): 8 tools with possibility to host 2 angular heads and 1 milling blade Tool change: automatic/manual (according to the model) Maximum diameter of milling tool: 20mm Milling blade maximum diameter: 180mm Number of standard clamps: 4 Adjustment of clamps positioning: automatic/manual(according to the model) Number of end stops: 2 Minimal lubrication system Automatic front protection door Power supply: 8,5 kW (12 kW for 7,5 kW electrospindle) Air consumption: 150 Nl/' Dimensions (length x depth x height): -- 5373 x 2550 x 2437 mm
