How cutting Focus Works in Fiber Laser Cutting Machine

The Raytools cutting head is a high-precision fiber laser cutting head designed for various industrial applications. Here's an overview of its cut focus mechanism: Cut Focus Principle: The Raytools cutting head utilizes a proprietary focus adjustment system to optimize the laser beam's focal point for precise cutting. This mechanism ensures: 1. High-quality cuts with minimal kerf width 2. Increased cutting speed and efficiency 3. Reduced heat input and distortion Cut Focus Components: 1. Focal Length Lens: A high-quality lens with a specific focal length (e.g., 125mm, 150mm, or 200mm) 2. Focus Adjustment Mechanism: A precision-engineered system allowing for fine-tuned focus adjustments 3. Collimator Lens: A lens that maintains the laser beam's collimation (parallelism) 4. Nozzle: A precision-crafted nozzle guiding the assist gas and laser beam Cut Focus Adjustment Process: 1. Initial Setting: The cutting head is set to a predefined focal length using the focus adjustment mechanism. 2. Laser Beam Alignment: The laser beam is aligned with the cutting head's optical axis. 3. Focus Adjustment: The focus adjustment mechanism is used to fine-tune the focal point, optimizing the cut quality. 4. Verification: The cut quality is verified, and adjustments are made as needed. Cut Focus Types: 1. Automatic Focus: The cutting head automatically adjusts the focus based on material thickness and type. 2. Manual Focus: The operator manually adjusts the focus using the focus adjustment mechanism. 3. Dynamic Focus: The cutting head adjusts the focus in real-time during cutting, compensating for material variations. Benefits: 1. Improved cut quality and accuracy 2. Increased cutting speed and efficiency 3. Reduced material waste and scrap 4. Enhanced system reliability and maintenance Technical Specifications: (Vary depending on the specific Raytools cutting head model) Focal length: 125mm, 150mm, or 200mm Focus adjustment range: ±2mm Cutting head accuracy: ±0.01mm Repeatability: ±0.005mm Troubleshooting Tips: 1. Verify proper focus adjustment and alignment. 2. Check nozzle condition and cleanliness. 3. Ensure correct laser power and frequency settings. 4. Consult Raytools documentation and support resources. #cncmachine #machine #fiberlasercuttingmachineformetal #cnccuttingmachine #lasercutting #welding #wood #cncoperator #cnc #lasercutting #cypcut #lasermarkingmachine
