PSAD SITUATION 159: Eccentrically Loaded Bolted Connection | CELE April 2023

CELE Past Board Exam Problem To learn more, enrol now to iReview Tutorial and Review Center: https://www.facebook.com/share/1AC24W... SITUATION: From the bolted connection shown, the diameter of each bolt is 16 mm. Given: P = 240 kN e = 300 mm a = 80 mm b = 80 mm 1. What is the direct shear stress (MPa) of the bolt? A. 246.0 C. 149.2 B. 175.7 D. 168.0 2. What is the reaction (kN) of the bolt number 8? A. 162.30 C. 109.66 B. 142.50 D. 104.33 3. When the maximum reaction of the bolt is 170 kN, what is the diameter of the most stressed bolt if it has an allowable shear stress of 276 MPa? A. 20 C. 28 B. 22 D. 25 Thanks for watching! Comment for questions and suggestions for future lecture in this series. Subscribe and hit the bell button to be notified for future posts. Check out our Review Center: https://www.facebook.com/share/1AC24W... #civilengineering #boardexam #engineering #structuralanalysis #structuralengineering #CivilEngineeringLicensureExamination #PRC #PSAD #loadanalysis #theoryofstructures #influencelines #CELESeptember2025
