Large size vertical screen printing exposure machine, screen copy unit, screen expose equipment

Large size vertical exposure machine / the large size free standing exposure system consists of the exposing lamp and the independent vacuum copying frame. High actinic light, even light distribution, constant power control, stable wavelength, high vacuum force and long service life of the lamp are the key features for preparing the high quality stencils for half tone jobs and highly dense line stencils.   EXPOSING LIGHTS (EV-LP3000) The reflector angle is computer-aid designed for the best light distribution. The reflector panel is the high quality material imported from Germany. The position of the exposing lamp can be freely adjusted in accordance to the printing frame sizes. The exposing time is controlled with timer.   VACUUM COPYING FRAME (EV-2030) Motor- driven flip over mechanism, the turning from loading position to the vertical position for exposing is being . Parameters: Model EV-2030 Max frame size 2000 X 3000 mm Max glass size 2400 X 3400 mm Cold way Cold wind forced cooling Exposure time 0 - 9999s Vacuum pump Oil-free compressor/pump Vacuum power 0 - 0.08 MPA Flip Pneumatic motor driven Power 380V X3P X 5KW Gross weight 700KG Model EV-LP3000 Power 3KW Voltage 380V 3PH 3.5KW Weight 90KG Dimension (L X W X H) 700*700*1300mm Any more technical or price query please feel free to contact with: Shanghai Hoting screen printing equipment Co.,Ltd ADD: No. 20-1, Siyuan Road, Yexie Town, Songjiang District, Shanghai, China Zip Code: 201600 Tel: +86-21-34121831 Fax: +86-21-34121832 Sales Manager: Andrew Zhao Mobile: +86 18001630038 (Whatsapp, Wechat (Hotingscreenprinting), Viber) QQ: 894927833 Skype: hotingscreenprinting03 Email: sales@hotingscreen.com / hotingscreenprinting@gmail.com Thanks for watching. We have solutions for different screen size and clients requirement.
