Raspberry Pi Pico, 7 Segment Displays and 74hc595 shift registers

Raspberry Pi Pico, MicroPython, 7 segment and 74hc595 shift registers. Want to know how to use this combination of components? Then this is the video for you. In this video I'll show you how to print out the 3d model that I designed in Fusion 360, based loosely on the Back to the Future time circuit. We'll then look at bit shifting and using shift registers with out projects, and how to use these with the 7 Segment displays. We'll finally have a play with MicroPython and shift registers with some sample code. To join the membership at bronze, silver or gold levels, head over to https://www.smarsfan.com/membership Thingiverse link to the STL files https://www.thingiverse.com/thing:485... For more information, tutorials, parts and more visit: https://www.smarsfan.com​ Enjoy this video? Buy me a coffee! https://www.buymeacoffee.com/kevinmca... Music by Epidemic Sounds https://www.epidemicsound.com/referra... Chapters 00:00:00 Raspberry Pi Pico, MicroPython, 7 segment and 74hc595 shift registers. 00:01:03 Session goals 00:01:52 Aims of this 3d printed project 00:03:58 Fusion 360 design 00:05:32 3d print the parts 00:07:12 Light Emitting Diodes 00:08:40 7 Segment Displays 00:10:48 Multiple Segment displays 00:16:16 Segment package Pin outs 00:17:48 Bit Shifting 00:20:39 Shift Registers 00:28:54 How shift registers work 00:33:00 7 Segment Numbers 00:35:00 Wiring up the Pico 00:37:27 Demo time 00:57:38 Next Steps 01:01:14 Membership programme launch #Pico​ #MicroPython​ #Robotics
