Wye Siphon Tube Use in pressure gauge ?

How it works Protects from high temperatures: In a high-temperature system, the fluid enters the siphon but cannot reach the gauge directly. As the hot fluid fills the siphon's coiled shape, it cools and condenses into a liquid. This liquid creates a protective barrier, and it is this cooler liquid that transmits the pressure to the gauge. Dampens pressure pulsations: The coiled shape of the siphon also helps to absorb rapid pressure fluctuations or surges, protecting the gauge from damage and ensuring more stable, accurate readings. Provides a water seal: The trapped condensate forms a water seal inside the siphon, preventing the hot steam or other vapors from reaching and potentially damaging the gauge's sensitive internal components. Maintains accuracy: By keeping the gauge at a stable, lower temperature, the siphon helps the gauge maintain its accuracy over time, as high temperatures can cause thermal expansion and alter readings.
